Specifications of Emerson Liebert ITON 600 BX
Model
ITON BX 600 VA.
Capacity
600 VA / 360 W
Input Voltage
220/230 VAC
Input voltage range
140-300 VAC
Frequency Range
50 Hz
AC Voltage Regulation (Batt. Mode)
±10%
Frequency Range (Batt. Mode)
50 Hz ±1 Hz
Transfer Time
Typica14-8 ms
Waveform (Batt. Mode)
Simulated Sine Wave
Overload
110% +/-10% Shutdown after 5 mins
Battery Type & Number
12 V/7 Ah x 1
Transfer Time
Minimum line break without transfer to battery 4 msec
To AC Mode
Green lighting
To Battery Mode
Green flashing
Fault
Red lighting
To Battery Mode
Sounding every 10 seconds
Low Battery
Sounding every second
Overload
Sounding every 0.5 second
Battery Replacements
Sounding every 2 second
Fault
Continuously sounding
Protection
Overload, discharge, and overcharge protection
PHYSICAL Dimension, DXW X H (mm)
279 x 101 x 142
Physical Net Weight (kgs)
4.2
Operating Environment
0-40 Deg C.
Storage Temperature
-15°C to 50°C
Humidity
0-90 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 40dB
